Install your rooftop solar panels with confidence using the SOLARWARE High-Rise Solar Panel Mounting Structure for 6 Solar Panels. Built from premium galvanized iron, this heavy-duty mounting system is designed to support modern solar panels rated between 400W and 650W.
Its elevated structure features 7.5-foot rear supports and 5.5-foot front supports, providing an efficient panel inclination while improving ventilation beneath the modules. The strong 80×40mm GI C-channel framework combined with 41×41mm slotted GI purlins offers exceptional rigidity and durability for long-term outdoor performance.
Delivered as a DIY assembly kit, every structural component is precisely manufactured for hassle-free installation on properly constructed concrete foundations.
Ideal for:
- Residential rooftops
- Farm houses
- Commercial buildings
- Industrial sheds
- Institutions
- Off-grid and on-grid solar projects
Designed and manufactured in India by SOLARWARE Industries, this structure is engineered to provide dependable support for your solar investment for years to come.
Key Features:
1. Designed for 6 High-Watt Solar Panels
Engineered to securely mount 6 solar panels ranging from 400W to 650W each in a single-row configuration, making it suitable for residential, commercial, agricultural, and industrial rooftop solar installations.
2. High-Rise Elevated Design
Features 7.5 ft rear legs and 5.5 ft front legs to provide an optimized tilt angle, improved airflow beneath the panels, easier maintenance access, and better performance in areas requiring additional installation height.
3. Heavy-Duty Galvanized Iron Construction
Manufactured using premium hot-dip galvanized iron C-channels and GI slotted channels for superior corrosion resistance, long service life, and dependable structural strength under outdoor conditions.
4. DIY Installation Kit
Supplied as a complete knock-down (KD) kit with structural members, mounting clamps, fasteners, and base plates for convenient transportation and on-site assembly by experienced installers.
5. Made in India
Manufactured by SOLARWARE Industries using precision-engineered components designed for long-lasting rooftop solar installations.Technical Specifications
Specification | Details |
|---|---|
Brand | SOLARWARE |
Product Type | High-Rise Solar Panel Mounting Structure |
Material | Galvanized Iron (GI) |
Panel Capacity | 6 Solar Panels |
Supported Panel Rating | 400W–650W Each |
Panel Layout | Single Row |
Front Legs | 4 × 5.5 ft GI C-Channels (80×40mm) |
Back Legs | 4 × 7.5 ft GI C-Channels (80×40mm) |
Rafters | 4 × 5 ft GI C-Channels (80×40mm) |
Purlins | 2 × 24 ft Slotted GI Channels (41×41mm) |
Base Plates | Included |
Installation Type | DIY Assembly Kit |
Mounting | Concrete Pillars Required |
Suggested Pillar Size | 1.5 × 1.5 ft × 2.5 ft |
Model | 6P-HR-7.5B-5.5F |
Country of Origin | India |
Box Contents
- 8 × Heavy Duty Base Plates
- 4 × Front Legs (5.5 ft)
- 4 × Back Legs (7.5 ft)
- 4 × Rafters (5 ft)
- 2 × Slotted GI Purlins (24 ft)
- 10 × Mid Clamps
- 4 × Z-Clamps
- Nuts, Bolts & Washers Set
- Installation Hardware
Disclaimer
- Solar panels are not included.
- Concrete foundation work is not included.
- Installation service is not included.
- Product is supplied as a DIY assembly kit.
- Professional installation is strongly recommended.
- Suitable foundation design depends on site conditions, wind load, roof type, and local building regulations.
- Product dimensions may vary slightly due to manufacturing tolerances.
- Always verify compatibility with your solar panel dimensions before installation.
Safety Precautions
- Install only on structurally sound rooftops or approved concrete foundations.
- Ensure all fasteners are tightened to the recommended torque before commissioning.
- Wear appropriate PPE including gloves, helmet, eye protection, and safety footwear during installation.
- Use certified fall-protection equipment when working at heights.
- Do not install during heavy rain, storms, or high winds.
- Periodically inspect all bolts, clamps, and structural members for loosening or corrosion.
- Do not exceed the recommended panel capacity or weight limits.
- Ensure proper earthing and lightning protection as per local electrical standards.
- Keep children away from the installation area during assembly.
- Installation should comply with local building codes and solar installation guidelines.
